Patio Cover/Lean-to carport KLEO 550L300 white aluminium

KLEO100

Patio Cover/Lean-to carport KLEO 550L300 white aluminium

SKU : KIT-000283

£1559

-100€ on the KLEO range

Patio Cover/Wall mounted carport with sloping roof
Width: 556cm & Depth: 300cm
Structure: Aluminum - White
Roof: Polycarbonate - Semi-transparent
Accessory and specific screws provided

2 years warranty

In stock - Delivery between 25/11 and 30/11
Free delivery

Technical characteristics

Number of plates

Maximum slope angle

80 °

Rainwater harvesting system

Gutter

gutter diameter

73 mm

Roof specification

UV30+

Ultraviolet protection factor

Yes

Use

Outside

Retractable roof

Product width

300 cm

Number of plates

Maximum slope angle

80 °

Rainwater harvesting system

Gutter

gutter diameter

73 mm

Roof specification

UV30+

Ultraviolet protection factor

Yes

Use

Outside

Retractable roof

Product width

300 cm

Maximum supported load

35 kg/m²

Eligibility extended warranty 5 years

Motorized

Fixing to the wall

Yes

Minimum slope angle

74 °

Wall mount type

Concrete anchors

External dimensions

556*300 cm

Passage height

Between 176 and 270 cm

Frame weight

35,24 kg

Structure finish

Mast

Wood fixing kit

Included

Number of posts

Structure treatment

Epoxy paint

Concrete fixing kit

Included

assembly time

8 H

Thickness of upper uprights

0,9 mm

Frame color

White

RAL of the structure

1055

Area covered

16,68 m²

Upright section

42.8X41/42.8X47

Roof protection treatment

UV protection

Space between adjustable legs

Yes

Fixing to the ground

Yes

Structure material

Aluminum

Post thickness

0,8 mm

Water repellent

Yes

Hardware included

Yes

Product length

556 cm

Product ridge height

270 cm

type of pergola

Leaning

Number of people recommended for assembly

Legal guarantee

2 an(s)

Eligibility extended warranty 10 years

roof material

Polycarbonate

Assembly

Delivered in KIT to assemble

Sealing

Silicone not included

Gutter position

On the front of the carport

Installation instructions

Yes

Shape

Rectangular

Accessories included

Yes (see instructions)

Column section

70x35 mm

Description

Patio Cover/Wall mounted carport with sloping roof
Width: 556cm & Depth: 300cm
Structure: Aluminum - White
Roof: Polycarbonate - Semi-transparent
Accessory and specific screws provided

The Lean-to KLEO aluminium Patio Cover provides the perfect cover to park your vehicle. Its modern yet simple design will be a harmonious match for all types of homes. May it be a contemporary or older styled house.

Thanks to its sturdy and stable aluminium posts, your KLEO Patio Cover will have a long life-expectancy. This material known for its resistance to rust is a big trend at the moment thanks to its durability, especially in humid conditions.

Its transparent polycarbonate roof will prolong your living space outside, with an efficiently covered exterior all year long.

Ideal as a Patio Cover, the KLEO model can also be declined as an reliable wall-mounted carport. The combination of an aluminium structure with polycarbonate roofing will efficiently protect any type of vehicle from all weather hazards thanks to remarkable waterproof and shockproof abilities.

Description: Pergola/Wall mounted carport with sloping roof
Frame material: Aluminium
Roof material: Polycarbonate
Frame colour: White
Roof colour: Semi-transparent
Dimensions: Width 556cm x Depth 300cm
Area covered: 16.5m²
Passage height: Minimum 225cm & Maximum 270cm (Sloped roof)

This DIY aluminium lean-to Patio Cover pergola/carport kitset is delivered ready to assemble yourself and contains:
- Powder-coated aluminium frame
- 3 thermo-lacquered aluminium posts (70x35x0.8mm)
- 18 polycarbonate plates (6mm thickness)
- 1 gutter
- Anchor kit for concrete or wooden floor
- Screws

As resistant as it is lightweight and waterproof, polycarbonate is a very popular material when it comes to roofing. It is as ideal to protect your vehicle as a carport as it is for your outdoor furniture as a Patio Cover. Way less fragile than glass, it is capable of withstanding many shocks caused by weather hazards like hailstone, snow or other falling debris. If you choose the KLEO as a carport, your car will be safe from bad weather.

If you’d rather choose KLEO as a pergola, its main asset resides in its brightness. The polycarbonate panels being semi-transparent, they will allow sunlight to pass through, which avoids darkening your exterior.

The KLEO model is also available with an Anthracite Grey frame and a grey semi-transparent roof. It is also available in many sizes: 500x300cm, 450x300cm, 400x300cm, or 300x300cm.

Pergola / Carport DIY kitset
Clear instructions, simple and fast assembly.
Get all relevant information for this product in the technical characteristics.
